Supply Ability :
500 Units per Year
Amplitude Range :
-120dB ~ +20dB
Output Impedance :
50Ω
Detection Capabilities :
Twisting, Bulging, Displacement, Tilting, Inter-turn Short Circuit, Phase Contact Short Circuit
Weight :
13kg
Frequency Range :
10Hz ~ 10MHz
Analysis Modes :
Horizontal (A/B/C) + Vertical (Before/After) + Expert Auto-Diagnosis
Dimensions :
370 × 300 × 170mm
Model Number :
XHBX1501
Frequency Accuracy :
0.005%
A/D Sampling :
16-bit Dual Channel High-Speed
Software Platform :
Windows/7/8/10 + Android App
Amplitude Accuracy :
0.1dB
Sweep Technology :
DDS Digital High-Speed (US Technology)
Delivery Time :
5-10 Working Days
Input Impedance :
1MΩ
Repeatability :
99.9%
Place of Origin :
Xi'an, Shaanxi, China
Certification :
CE, ISO
Payment Terms :
T/T
Connectivity :
USB, WiFi, Bluetooth
Brand Name :
XZH TEST
Measurement Speed :
<60s per Phase, <10min per Transformer
Packaging Details :
Aluminum alloy carrying case with custom foam padding, export-grade corrugated carton
Sweep Points :
40,000 Points (Linear), 2,000 Points (Segmented)
Frequency Resolution :
0.25kHz, 0.5kHz, 1kHz
Applicable Transformers :
63kV ~ 500kV Power Transformers
Price :
Negotiable
Test Method :
Frequency Response Analysis (FRA) per DL/T911-2016
Report Generation :
Automatic Word Document with Color Printing
Output Amplitude :
±20V
Operating Temperature :
-10℃ ~ 40℃
Operating Humidity :
<90% (Non-condensing)
MOQ :
1 Unit
Power Supply :
AC 220V±10%, 50Hz
